How To Articles › Canon
Applies to: Canon cameras | macOS & Windows | Last Updated: Jul 12, 2024
Important: Troubleshoot Canon Camera Connection. Canon camera compatibility in Visere Captura depends on the Canon SDK version integrated into your installed Visere Captura version. If your camera is not supported by the Canon SDK, it may not connect or capture reliably.
1. What You’re Trying to Determine
If you’re having issues running Visere Captura with your Canon camera, the fastest way to troubleshoot is to determine whether the problem is caused by:
- The camera / cable / port / firmware
- Canon’s SDK compatibility on your OS
- A software conflict (another app controlling the camera)
- Visere Captura behavior vs. Canon’s own EOS Utility
2. Step 1: Confirm Canon SDK Camera Support
First, verify that your Canon camera model is supported by the Canon SDK used by your installed version of Visere Captura. Canon publishes an official SDK compatibility list here:
Canon EDSDK Compatibility List
Tip: Check the Visere Captura Release Notes to see which Canon SDK version is integrated in your build. Different Visere Captura versions may use different Canon SDK drivers.
Second, for some older Canon cameras, "Keep live view on after capture" must be enabled. Click the tree dots next to Live View once the camera is connected and enable the option from the dialog that pops up.
Third, in the Canon camera menu, make sure AF Method is set to anything other than Face Tracking or any other tracking-based focus mode. It’s also worth trying different AF Method settings, as long as tracking is not enabled.
3. Step 2: Test with Canon EOS Utility
To determine whether the issue is camera/OS related or Visere Captura related, test the camera using Canon’s own software.
Test steps
- Download and install Canon EOS Utility for your camera model and operating system from Canon’s support site.
- Connect the Canon camera via USB (avoid hubs during testing when possible).
- Launch EOS Utility and test basic detection and capture.
How to interpret results
- If EOS Utility cannot detect/control the camera: the issue is likely camera, cable/port, driver, firmware, or OS related.
- If EOS Utility works but Visere Captura does not: the issue may be related to Visere Captura’s SDK integration or a workflow/setting difference. Continue below and then contact support with your findings.
4. Step 3: Eliminate Software Conflicts
Canon cameras can typically be controlled by one application at a time. If another application is running in the background, Visere Captura may fail to connect or may behave unpredictably.
Close other camera-control apps
- Adobe Lightroom
- Canon camera utilities
- Any third-party tethering/camera-control tools
Restart for a clean test
- Quit all camera-related applications.
- Restart your computer to ensure background processes are closed.
- Confirm those apps are not set to launch automatically at login/startup.
- Launch Visere Captura and test again.
macOS note: If you are using a PTP-style connection workflow, ensure Apple’s Preview app is not running during testing.
5. Step 4: Update OS, Visere Captura, and Firmware
Compatibility changes can occur across OS updates and camera SDK updates. For best results, ensure you are running:
- The latest version of your operating system (macOS or Windows)
- The latest version of Visere Captura
- The latest firmware available for your Canon camera model
Note: Different versions of Visere Captura use different Canon SDK drivers. Some older Canon SDKs may be incompatible with newer operating systems.
6. When to Contact Support
If you still cannot connect after completing the steps above, contact Pictomic support and include:
- Canon camera model
- Operating system version
- Visere Captura version
- Whether EOS Utility works (and what it can/can’t do)
- Whether other camera-control apps were closed/disabled during testing
Email: support@pictomic.com
